Welded Pipe Machine

Zhongtuo welded pipe making mill, HG76 Pipe roll forming machine

HG76 welded pipe making mill will be made to gantry type for processing large diameter pipe in a high speed. As its name shows, HG76 gantry type pipe making mill will be displayed like a dragon. When it works, it has fast speed like a dragon running. This type machine is quite good for who need to operate a pipe factory. Here are two reasons for your reference: for one thing, HG76 supports more types of welded pipe in large range pipe diameters. For another thing, as fast and high speed, HG76 welded pipe making mill could make pipe in great quantity.

HG76 welded pipe making mill features:

  • High speed, low energy consuming. And low workforce needed. The electricity of this machine, we have process by special technology, so it can work within low energy consuming.
  • Large range pipe diameter supported.
  • We provide free service, free installation and free training service.
  • Easy to install and easy to change moulds.
  • The main roll forming machine also could use together with other roll forming machine to make different types finished product just by changing mould.
  • Durable to use, normally speaking, and this machine could use more than 20 years.
  • If you need, our machine also can help you curve time, date, company name or other words on the finished pipes.

Work flow of HG76 welded pipe making mill:
welded pipe machine

Main elements of HG76 welded pipe making mill:
Double head uncoiler 1
Hydraulic shearing and manual welding machine 1
Coiler feeder to accumulator 1
Accumulator 1
Forming and sizing mill 1
F5-200kw solid state H.F welder 1
Electric control system 1
CNC flying friction saw 1
Roll out table Steel frame, if you need the automatic one then we can change for you
Tech service The tech team needs to stay at customer factory 6 months, training customers till everything works well. And the all fee will be covered by customer.

pipe making mill

Light Steel Keel Rolling Machine

Zhongtuo wall angle roll forming machine, wall angle bead producer

Wall angle beads normally will be used together with C channel, U channel and others and the sizes are different according to the customer needs. And for without punching wall angle, there are also two types, with folding age about 1mm or without folding edge.  All those two types could be made by our machine one. Even If you have four to five different sizes needed, our machine also could make for you by our one wall angle roll forming machine.

Here is one picture for illustrating what I mean above:
wall angle roll forming machine

All those two types could be made by one machine with various sizes.

Work Flow of wall angle roll forming machine
wall angle roll forming machine1

Basic parameters of wall angle roll forming machine
Supported material Processing material: GI

Material thickness: 0.4-0.8

Material hardness: 550 MPA—350 MPA
Working speed 20m/min
Length about 3000…800…1400
Roller fixer Guide column
Material of rollers GCr12MoV
Number of rollers 10 rollers

wall angle roll forming machine

ZTRFM has been dedicating to roll forming technologies for over 2 decades and now boasts strong experience, capabilities, innovative thinking and roll forming expertise to provide perfect roll forming solutions to our clients. At ZTRFM, we can help build a better future for you and your customer.



At ZTRFM, various payment terms are acceptable,you can choose what is convenient for you. Also we offer excellent after-sales services.  Typically , we offer 1 year warranty and whole life technical support. Our engineers can work overseas and clients can also come to be trained to how to operate machines.



For more information, please contact me at Whatsapp:008618730769688 or send an email to cnzt005@zhongtuocn.com

FAQ

  1. IS AFTER SALES SERVICE AVAILABLE?

Yes, we offer 7x 24hours online support and our engineers can work oversea to help.



  1. HOW CAN I GET TO YOUR FACTORY?

a. First fly to Beijing airport and then go from Beijing Nan to Cangzhou Xi (1 hour) by  high speed train . Then we can pick you up at the railway station.

b.   First fly to Shanghai Airport and then go from Shanghai Hongqiao toCangzhou Xi(4.5 hours)  by high speed train. Then we can pick you up at the railway station.



  1. WHAT IF SOME PARTS BREAK?

We offer warranty of 12 months ,during which free spare parts are available if some parts of the machine break to be irreparable. Besides, we also offer whole life technical support which means we will still offer technical advice 1 year after your purchasing. We can discuss to help you out.



  1. CAN YOU TAKE CHARGE OF TRANSPORT?

Yes, we have strong expertise in this area for years and you can trust us.







Light Steel Keel Rolling Machine

Zhongtuo wall angle roll former with punching holes

Here are some pictures for your reference:
1

Features of Zhongtuo wall angle roll former with punching holes:

  1. Our machine could make roll forming and punching as a whole, and then the working speed could be enhanced greatly.
  2. Punching hole types could be customized according to your needs.
  3. For the punching dies could be changed fast and easily.
  4. Low energy consuming and high working speed.
  5. Beautiful shape of machine, it takes small space in the factory, motor will be covered in the steel frame as a whole.
  6. Thick and hard steel frame of the machine for long time use.
  7. Painting part, we will choose the China homemade best painting for long time anti corrosion.

Work flow of wall angle roll former with punching holes:
2

Basic parameters of this machine:

Description Introduction Customer needs
Working  efficiency 5-15m/min
Thickness of Material 0.2-0.55mm According to your needs.
Width of material 35mm—65mm According to your needs.
Control system PLC Delta
Uncoiler system 1.5 Ton 500mm
Forming by rolling Roll 9 rows
Roller material Gcr12MoV quenched
Shaft and the diameter of axle 45#Aluminium processing

diameter of  40mm
Main part power 3kw
Hydraulic motor power 3kw
Hydraulic pressure 20Mpa
Scissor material Gcr12MoV quenched
length tolerance 3m±1.0mm
voltage 380V, 50HZ,3 phase Adjustable by customer
Frame form Gantry arch type
Driving Method Gear box
Color Yellow and blue adjustable
Working  Size length*Width*Height
Coiler feeder 1.5kw
Punching machine Gcr12MoV quenched
Punching moulds Each type one set

wall angle roll forming machine

Welded Pipe Machine

Zhongtuo carbon pipe producer, factory welded pipe machine producer

HG127 carbon pipe producer could be used to make pipes from diameter from 20-127mm within the wall thickness 1.0-4.0mm, and the working speed could reach 30-80m/min.

We design HG127 carbon pipe producer in the shape of gantry type for reaching high speed meanwhile supporting large range pipe diameter. This machine size is quite big, so when prepare factory, you need to at least prepare 9 meters long and 5 meters height. For the cutting saw, this machine takes servo flying cutting saw for making machine totally automatic and fast speed.

  1. Brief introduction of HG127 carbon pipe producer :

HG120 is mainly used for producing pipes diameter between 50—152 mm (round pipe), square pipe size among 40-120mm, and rectangle pipe range among 60—40 100—140 within the wall thickness from 2.0-5.0mm.

  1. Basic information of HG127 carbon pipe producer:
  • Supported material(the material should be up to YB189-64 standard):
  1. Carbon steel, steel.
  2. Coil width: 160-480mm
  3. Coil thickness: 2.0-5.0mm
  4. Inner diameter: 550-610
  5. Out diameter:1000- 1600mm
  6. Max weight: 6 Ton

2).Finished pipes size samples:
a: Round pipe: 50-152mm
b: square pipe:40x40mm, 50x50mm,100x100mm and 120x120mm
c: rectangle pipe: 0—40 /60—80 /140—100
d: wall thickness: 2/5mm
e: pipe length: customized according to your needs.
Working speed: 30-90m/min
3).Solid state H.F welder 400KW
4).Water used per hour 40-50T/h, the reservoir should be 70 cubic meter
5).Work flow of HG127 carbon pipe producer.
Loading car-decoiler-leveling device and feed coil device-welding two coils together machine- deliver /accumulator-leveling second time/roll forming the first time–device prepared for welding–rolling shape part–remove welded scare part–cooling down part–sizing-pipe straightening part–flying cutting saw– roller bed–runout table–packing
HG127 pipe machine

Metal Door Machine

Metal door frame roll forming machine

Metal door frame machine is a kind of roll forming machine which is developed to make various types metal door or window frames, reinforced, fire stop doors, etc by roll forming method. By this one metal door roll forming production line, you can finish punch holes, cutting end connection part and others. After roll forming by our production line, we could make very smooth and beautiful door frame without any scratch on surface. This metal door frame production line is composed by the following elements: De-coiler, feed & leveling device, punching machine with holes punching moulds, main roll forming machine, cutter, run-out table, etc.  Those machines are customized according to the drawing profile of metal door frame.

Here is the picture for your reference:

shutter door frame machine
shutter door frame machine

Why metal frame is popular those days?

  1. For one thing, in the market now there are many kind of cladding on metal, the metal could be made like wood, stone and others. So you can make door frame as wood, as stone instead of metal but the cost will be lowered down greatly.
  2. The advantages of hollow metal doors are Broad Commercial Applications, Fire Resistant, Insulated and Sound-Rated, Durability. Door Frames are widely applied in related structure industry because of its advantage compared with other materials.
  3. Metal door frame is easy to change and easy to install. For modern society building, the metal door frame could be produced in batch in a few minutes. So the cost of them is low.



What Zhongtuo metal frame machine can do for you?

  1. Zhongtuo metal door frame machine can help you make door frame in batch, the working speed could reach 50m/min.
  2. Support many types of door frame. If the drawing profiles do not have too much difference, then they could be made by one machine.
  3. Easy to operate. Zhongtuo metal frame machines are fully automatic, so you do not need to do anything, and then it will run and make production automatically.
  4. For door frame, accuracy is quite important. Our machine takes good PLC and sensor, so it can make sure the accuracy within 1.5mm.

Main elements and specifications of metal frame roll forming machine:

            Metal Door  frame Roll Forming Machine
Punching machine with moulds Capacity 40T
Forming Roller Stations: 24 Stations
Forming Roller shaft: 65mm, 40Cr, quenching, treating
Forming rollers GCr15, quenching, hardness HRC50-58º
Forming Speed: 12 meters / min
Main motor: 7.5kw
Feed material thickness: (0.5-2.0) mm— L
Line speed Adjusted by Frequency Inverter
Power: 380V/3ph/50Hz
Run-out table mode: roller style
Line dimension: 15000—1000—1000mm

Metal Door Machine

Metal roofing galvanized aluminum corrugated steel sheet making machine

20150826104937

metal roofing roll forming machine production process

uncoiling–feeding material into machine–roll forming–measuring length–step formed–auto cutting–products receiving

20150826105030



20150826105041



Spare parts ( for free)

1. Easy damaged parts: conk 2 pcs, fuse-link 4 pcs;

2. Rubber mat 1 pcs;

3. Bolt spanner 1 pcs

1. Installation and training of machine manufacturer:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the roll forming machine for sale , and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service of roll forming machine for sale
a.One year guarantee for whole roll forming machine for sale.
b.24 hours technical support by email or calling
c.If there is any problem found of steel roof sheet roll forming machinery, we will repair roll forming machine for sale for free in one year.

Metal Door Machine

Stud and truss profile roll forming machine light gauge steel framing machine

Stud and truss profile roll forming machine light gauge steel framing machine
Specifications:
1.Tower structure for main body.
2.CNC rolling the rollers.
3.Poilishing the rollers surface shinning.
4.PLC control with automatic

Product Description:

Basic information of furring keel roll forming machine
Description Introduction Customer needs
Working efficiency 0-25m/min Adjustable
Thickness of Material 0.6mm Adjustable
Width of material 130mm Adjustable
Control system PLC Delta
Uncoiler system 1.5Ton
Forming by rolling Roll 12 rows
Roller material

GCr12MoV (SKD11) Aluminium processing after

quenchin HRC58-62, Chrome

Shaft diameter of axle

45#Aluminium-processing ,

diameter of axle=40mm

Main part power 5.5kw
Hydraulic motor power 3kw
Hydraulic pressure 12Mpa
Scissor material Cr12Mov, herd steel HRC 58-62°C
length tolerance ±1.5mm
voltage 380V, 50HZ,3 phase adjustable
Frame form Grant type frame
Driving Method Gear box
Color Customize
Size

length*Width*Height

5.2*1.25*1.5m
weight

3.5T
Package Nude package in 1*20GP container
Delivery date 30 working days

Samples of Trusss our Machine could make:



forming machine

Contact:

Office:Room 807, Building 6, Taida International, Yunhe District, Cangzhou, City, Hebei Province, CHINA
Factory:YingBin Road in Industrial Development Zone of Botou City,Hebei Province,CHINA
TEL:+86 317 5206885  TEL:+86 317 2191158

FAX:+86 317 5206880

PHONE:+86 15127778288

Skype: cnzt002@zhongtuocn.com

WEB SITE: http://www.rollsformingmachine.com/

MAIL:ceo@zhongtuocn.com



Metal Door Machine

Steel high quality metal sheet rolling steel roof cold roll forming machine

Main parts of roof roll forming machine:

1 uncoiler and its base
2 coil sheet guiding equipment
3 roll forming system
4 hydraulic pressing equipment
5 post cutting equipment
6 hydraulic station
7 controlling system
8 supporter table

Technical parameters:

  1. material spec: colored steel sheet, galvanized steel sheet, aluminium sheet
  2. thickness of coil sheet: 0.3-0.8mm
3.roller material: high grade NO.45 forged steel, with hard chrome plating on the surface of roller with thickness 0.05mm
4.shaft material: high grade NO.45 carbon wrought steel
5.cutting blade: Cr12 mould steel with quenched treatment
6.diameter of shaft: 70-90mm
7.thickness of medium plate: 14-20mm
8.main frame: 300H/U steel
9.number of forming steps: 15 rows
10. productivity: 1-3m/min
11.main motor power: 5kw
12.hydraulic station power: 4kw
13.hydraulic pressure: 10-12MPa
14.controlling system: PLC computer control
15.Voltage: 380V 3Phase 60Hz or at buyer’s requirement

Advantage of roof roll forming machines

1 automatic hydraulic glazed tile making machine
2 ISO&CE
3 no scratch smooth
4 good quality
5 durable tile forming machine

Packaging & Delivery

Packaging Details:

roof tile making machinery company

1). Tighten to container with steel wire rope and welded machine with container by angel iron

2). Main forming machine and un-coiler is naked(If you need we can also packed with water-proof plastic)

3). PLC contral system and motor pump are packed in wooden box with water proof paper coverage

Delivery Detail: within 25 days after we received the deposit,roll forming machin

Metal Door Machine

Automatic metal roof corrugation sheet machine

Automatic metal roof corrugation sheet machine

1.Suitable material Color steel sheet , galvanized steel sheet,aluminum sheet
2.Installation Dimension (L*W*H): 6.5m*1.5m*1.4m
3.Main motor power 3KW with Cycloidal reducer
4.Hydraulic station power 3KW
5. Hydraulic oil pump CB-E 310
6.Thickness of material 0.3mm~1.0mm
7.Diameter of principal axis Φ70-90mm
8.Material expand width 1000mm
9.Electric tension 380V 3phase 50HZ or as the customer’s requirements
10.Material of roller High grade 45# forged steel plated with hard chrome plating
11.Controlling system PLC
12.Processing speed 8-12m/min
13.Processing precision within 1.00mm (depend on design)
14.Material of cutting blade Cr12 mould steel with quenched treatment
15.Kind of drive 0.6 inch chain link bearing model 6210
16.Roller station 8-20 Rollers
17.Roller material high grade 45#steel; Cr12 quenching
18. Leak frame load-bearing 4.6T

Passive uncoil pulled by roll forming system

Loading capacity Uncoiling width Inner diameter
1.5T 300mm 450-550mm

metal door making machine, shutter door roll forming machine, rolling machine



automatic metal roof corrugation sheet machine

Usage: Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat, parallel and everything is uniformity.Please refer to the equipment regulation to knowthe function of locate angle iron.



metal door making machine, shutter door roll forming machine, rolling machine



Forming device of shutter door roll forming machine

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working

Feature : Ensure stability , precision and lifetime.

Spare parts ( for free)

1. Easy damaged parts: conk 2 pcs, fuse-link 4 pcs;

2. Rubber mat 1 pcs;

3. Bolt spanner 1 pcs



1. Installation and training of machine manufacturer:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the roll forming machine for sale , and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service of roll forming machine for sale
a.One year guarantee for whole roll forming machine for sale.
b.24 hours technical support by email or calling
c.If there is any problem found of steel roof sheet roll forming machinery, we will repair roll forming machine for sale for free in one year.

what makes us better than others?

Corrugated Metal Roof Profile Sheet Making Machines

1. Professional 15 years’ rich experience!a.Specialized in Corrugated Metal Roof Profile Sheet Making Machines since 1998;
b.Keeping improving the quality.
2. Low price Save your money from every part!a. Low labor cost;b. Convenient transportation;

c. Complete supporting industries.
3. PLC Ensuring high accuracy and easy to operate!Full Automatic: Just input length of the sheets and numbers of the piece you need, then the machine will start to work as your order.
4. OEM / ODM Customers design, color & logo are also accepted!Our specialized experts and skilled workers keep devoting their hard working to ensure the machine with high quality.

5. TWO-Years warranty, whole life service

 Keep troubles far away from you!Within the TWO-YEARS period, we could supply you the replacement parts free of charge for any damaged parts caused by quality problems .



Metal Door Machine

Roof Panel Forming Machine Making Metal Construction Materials

Roof Panel Forming Machine Making Metal Construction Materials

Roof panel forming machine main structural features:

1, roof molding machine structure is simple, beautiful appearance, because the machine uses steel structure, the overall processing after welding, so the structure is simple and reasonable, strong deposit carrying capacity, smooth and reliable operation.
2, roof roll forming machine equipment of high quality forged steel 45 precision manufacturing, the surface of the hard chrome plating, to achieve high roll surface hardness, smooth, sheet molding surface without injury.
3, roof molding machine rollers 45 steel after quenching, in order to improve the strength, hardness and other mechanical properties of the shaft.
4, the main components of the electrical control system of all imports.
5, roof molding machine is fully automatic fixed length forming cut length precise positioning, plate-shaped head and tail neat appearance.
6, low roll forming equipment noise, high efficiency.

HTB1OuK9HXXXXXblaXXXq6xXFXXX8

Specifications Roof Panel Forming Machine Making Metal Construction Materials:
1)CE.
2)14 months warranty
3)made to order.
4)10-year exper.

Roof Panel Forming Machine Making Metal Construction Materials:

ALLSTAR MACHINERY:Roof Panel Roll Forming Machine,Roof Deck Roll Forming Machine,Roof Sheet Roll Forming Machine

Specifications of Roof Panel Roll Forming Machine, Roof Deck Roll Forming Machine:

1. Material Width: 280mm & 260mm.
2. Material Thickness: 0.4mm-0.8mm.
3.Suitable Raw Materials: Pre-painted coil; Zinc coated plate.
4. Forming speed: 12-15m/min.
5. Forming Stations: 11
6. Material of rollers: Good 45#, rigid chrome coated.
7. Power of main motor: 3kw.
8. Dimensions: about 3800mm x 1200mm x 1380mm.
9. Power: 380V 50HZ 3phase 1 phase voltage 220V

The equipment include:
1. Un-coiler, 1 set
2. Main Roll forming machine, 1 set
3. Hydraulic cutting, 1 set
4. Hydraulic station, 1 set
5. Electric controlling system, 1 set
6. Product rack (un-powered), 1 set
7. Instruction Book, 1 piece
We can design and make according to customers requirement.
Major Products and Services:cold roll forming machine for corrugated tile, glazed tile, C Purlin, Z Purlin, roof panel and wall panel, etc.

HTB1tjH4HXXXXXbzXpXXq6xXFXXXG

metal roofing roll forming machine production process

uncoiling–feeding material into machine–roll forming–measuring length–step formed–auto cutting–products receiving

HTB1J66JHXXXXXcxXpXXq6xXFXXXB

1. Installation and training of machine manufacturer:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the roll forming machine for sale , and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service of roll forming machine for sale
a.One year guarantee for whole roll forming machine for sale.
b.24 hours technical support by email or calling
c.If there is any problem found of steel roof sheet roll forming machinery, we will repair roll forming machine for sale for free in one year.



The Roof Panel Forming Machine can custom made。If you need this type machine you can contact us .We will give you the price.

Office:Room 807, Building 6, Taida International, Yunhe District, Cangzhou, City, Hebei Province, CHINA
Factory:YingBin Road in Industrial Development Zone of Botou City,Hebei Province,CHINA
TEL:+86 317 5206885 TEL:+86 317 2191158 FAX:+86 317 5206880 PHONE:+86 15127778288 QQ:497059080
WEB SITE:http://www.rollsformingmachine.com/ MAIL:ceo@zhongtuocn.com
